AVT-1660

AVT -1660 Digital Standards Converter (formerly known as the CDM-660) allows you to freely convert between various worldwide television standards.

Manufacturer: AVToolbox
SKU: AVT-1660
Print

EOL NOTICE
The AVT-1660 has been scheduled for End of Life.  There is no alternative product available for this item. If you require a
AVT-1660 for your project, please contact your sales representative.

AVT -1660 Digital Standards Converter (formerly known as the CDM-660) allows you to freely convert between various worldwide television standards. The input system can be NTSC 3.58, NTSC 4.43, PAL, PAL-M, PAL-N or SECAM and the output system can be either NTSC or PAL. The AVT-1670 provides inputs and outputs for Composite Video signals. This high quality digital device converts between 50 and 60 Field Rates and between 525 and 625 Line Rates.

Full Digital Conversion Technology
Built-in color Bar Generator
Input Video: Composite or S-Video
Input Standards: NTSC 3.58, NTSC 4.43, PAL, PAL-M, PAL-N, SECAM
Automatic Input Standard Detection
Output Video: Composite or S-Video
Output Standards: NTSC 3.58, PAL
Sampling Frequency: Y=13.5MHz, R-Y=6.75MHz, B-Y=6.75MHz
Digital Code Bit: R=8 bits, G=8 bits, B=8 bits
Line Conversion: 525 to 625, 625 to 525
Field Conversion: 60 to 50, 50 to 60
Size: 1.8" High x 9.3" Wide x 5.1" Deep (45mm x 236mm x 130mm)
Weight: 14 ounces (0.4kg)
115VAC to 5VDC Power Adapter Included
One-Year Limited Warranty
