Cable Required: 18 AWG DC coaxial harness wired to 3 position Phoenix
Compliance: CE, FCC Part 15 Class A, RoHS, cTUVus
Connectors: (6) Phoenix 3 pos. power ports
(1) IEC-320 AC inlet, fused
Tolerance: Operating: 32 to 104°F (0 to 40°C);
Storage: -4 to +140°F (-20 to +60°C)
Tolerance: Up to 80% non-condensing
Enclosure: Powder Coated Steel
Power: 100-240 VAC, 50/60Hz, 1.5A max.
Consumption: 150 watts maximum
Fuse: There are two internal AC-mains fuses. These fuses are not userreplaceable.
Rating: 5x20mm, 2A, 250V
Type: Littelfuse P/N 0218002.HXP.
DOUBLE POLE/NEUTRAL FUSING
Output: 5 Volts DC at 10 amps maximum
12 Volts DC at 4.2 Amps maximum
Size: 7.25” W X 1.75”H X 6.75”D (18.4 cm X 4.45 cm X 17.1 cm)
Weight: 3 Lbs ( 1.36 Kg )
Accessories: 1U dual rack mount kit (PN: 400R3379)
DC coaxial cable with tinned conductors (PN: 8450333)
